picoZ80: RP2350-Based Drop-In Z80 CPU Replacement with WiFi Management for Vintage Computers
By
rickcarlino
Master baker tier. Every paragraph earns its place on the tray.
Summary
The picoZ80 is a custom PCB designed as a drop-in replacement for Z80 CPUs in vintage computers. It uses an RP2350B microcontroller (dual-core 150MHz Cortex-M33) with programmable I/O state machines to provide cycle-accurate Z80 emulation. The device offers enhanced features including faster processing, more memory, virtual devices, networking (WiFi, Bluetooth), rapid application loading from SD card, and WiFi management capabilities. It's specifically designed for legacy Z80-based systems like the Sharp MZ-700, allowing modern upgrades while maintaining compatibility with vintage hardware.
Key quotes
· 4 pulledThe picoZ80 continues the tranZPUter theme, replacing a physical Z80 in a host or industrial computer with a faster CPU, more memory, virtual devices, networking (WiFi, BT), rapid application loading from SD card and WiFi management.
It is a custom PCB designed to drop directly into the Z80 DIP-40 CPU socket of any legacy Z80-based computer.
Rather than using a discrete Z80 processor, the board hosts an RP2350B microcontroller — a dual-core 150MHz Cortex-M33 device capable of running at up to 300MHz — whose programmable I/O (PIO) state machines take full control.
Cycle-accurate Z80 emulation using PIO for Sharp MZ-700 and other vintage computers.
